Features
- Number of stations: 8 (expandable to 54 - metal, 38 - plastic)
- Type: Modular
- Enclosure: Outdoor plastic, metal
- Backlit display
- Independent programs: 4
- Start Times per program: 8
- Max station run time: 12 hours
- Simultaneous program operation: 2
- Warranty period: 5 years
Specs
- Transformer input: 120/230 VAC
- Transformer output: 24 VAC, 1.4 A
- Station output: (24 VAC): 0.56 A
- P/MV (24 VAC): Up to 0.56 A
- Sensor inputs: 1
Approvals
- CE, UL, cUL, RCM, FCC
- Plastic Wall Mount: IP54
- Metal Wall Mount (includes stainless): IP54
- Plastic Pedestal: IP24
Overview
ICC2 is a value-packed, light-to-mid size commercial irrigation controller that delivers more than you expect, just like its famous predecessor. It is designed to control larger projects (up to 54 stations) and offers the water savings you expect from a Hunter controller.
ICC2 can run any two of its four automatic programs simultaneously. The ICC2 face-pack and station output modules (with enhanced surge protection) are compatible with the original ICC controllers in four and eight-station increments. An optional expansion module allows up to 54 stations in ICC2 metal enclosures and 38 stations in plastic enclosures.
ICC2 offers simple programming with a high-visibility back-lit display and customisable language overlays. It also includes advanced features like Easy RetrieveTM memory backup, Cycle and Soak, and Seasonal Adjustment.
ICC2 controllers are pre-wired for remote control with Hunter ROAM and ROAM-XL transmitters and have built-in Solar Sync® for automatic water savings, with an optional sensor. ICC2 is available as a plastic outdoor wall mount, metal outdoor wall mount, stainless steel wall mount, or plastic pedestal. Optional matching metal pedestals in grey or stainless are also available.
Includes Power Cord
WATERSENSE® SMART WATERING CONTROLLER BY ADDING SOLAR SYNC
Adding a Solar Sync™ to your Hunter controller transforms into an intelligent controller using local weather conditions to tailor watering schedules to actual requirements on the site. A Hunter controller with Solar Sync has a proven detailed list of water-saving features, with approval by the EPA as a WaterSense Smart Watering Controller.
EASY RETRIEVE™ MEMORY
The controller offers a manual backup feature that saves and stores scheduling and set up information. In case of a failure, you can recover settings at any time.
ONE-TOUCH MANUAL START AND ADVANCE
Allows any program to be started manually by simply pressing and holding the right arrow key. Advance through stations in a program by pressing the right arrow key again.
PROGRAMMABLE RAIN DELAY
The Programmable Rain Delay feature incorporates a user-specified number of days to keep the controller in the OFF mode, allowing the system to revert to scheduled irrigation automatically. Preventing watering during an extended period of inclement weather will automatically resume watering without requiring a return visit to the controller. The controller displays the number of days remaining before watering continues.
QUICK CHECK™
The QuickCheck feature makes field wiring issues easy to assess with the push of a button. QuickCheck displays an ERR message when detecting a field wiring short on a particular station number.
NON-VOLATILE MEMORY
This feature offers protection against unreliable power, retaining current time, date, and program data.
AUTOMATIC SHORT CIRCUIT PROTECTION
Automatic short circuit protection is a feature found in all Hunter AC powered controllers. This feature automatically detects electrical faults, which are occurred by wiring issues—skipping Stations that are affected, allowing all other stations to water normally as programmed. There are no fuses to blow or internal circuit breakers to trip to avoid a complete irrigation system shutdown.
SEASONAL ADJUSTMENT: GLOBAL OR AUTOMATIC UPDATES WITH SOLAR SYNC
This feature allows for quick adjustments to irrigation run times through a percentage scale. During peak season, set the seasonal adjustment to 100%. If weather conditions require less water, enter the appropriate percentage value (i.e. 50%) to cut down irrigation run times without adjusting each station in the program. This model offers two different ways to use Seasonal Adjustment to reduce water usage: Global and Daily.
Global: The Global option provides a Seasonal Adjustment percentage to all station Run Times on all of the controller's Programs.
Daily: With the addition of a Solar Sync ET Sensor, the controller can implement daily adjustments based on measured local weather automatically.
CYCLE AND SOAK
This water-saving feature allows the operator to specify a maximum cycle time for every single station in hours, minutes, or seconds, followed by a minimum soak time, to prevent runoff from slopes or saturated soil. The operator can enter any run time, and the controller will automatically divide it into cycles to allow the water to absorb during the soak periods. The feature is adjustable for each station or Block of stations for unique soil and site conditions.
DELAY BETWEEN STATIONS
Users can program a delay between stations as the controller advances from one station to the next. This delay can range from a few seconds (to permit slow-closing valves additional time to close) to a much more extended time (to allow pressure tanks time to recharge), based on user requirements.
TOTAL RUN TIME CALCULATOR
This calculates the total duration of a program based on all of its station run times. This can be used to calculate the end time of a program.
