Features:
- Provides extremely uniform coverage over large diameters
- Only one moving part, which translates to longer product life
- Available in standard and low angle models
Overview
Wobblers produce droplets resistant to wind drift and evaporation and distribute them in a gentle, rain-like pattern.
20mm Male BSP thread
The minimum recommended riser height is 0.46 m.
Standard Wobbler Sprinkler:
- Nozzle Sizes: 2.38mm - 5.56mm
- Flow Range: 177 - 1735 L/hr
- Pressure Range: 0.69 - 2.07 BAR (10 - 30 PSI)
- Diameters of Coverage: 10.4m - 16.0m (0.46m in height)
Low Angle Wobbler Sprinkler:
- Nozzle Sizes: 2.38mm - 5.56mm
- Flow Range: 177 - 1735 L/hr
- Pressure Range: 0.69 - 2.07 BAR (10 - 30 PSI)
- Diameters of Coverage: 8.8m - 14.6m (0.91m in height)
Nozzle Specifications - Standard and Low Angle
| Nozzle & Flow |
Pressure - Bar |
||||
|
0.69 |
1.04 |
1.38 |
1.72 |
2.07 |
|
| #6 Nozzle - Gold (2.38 mm) | |||||
| Flow (L/hr) |
177 |
216 |
250 |
279 |
307 |
| SA Diameter at 0.46 m ht (m) |
10.4 |
11.9 |
12.7 |
13.3 |
13.4 |
| LA Diameter at 0.46 m ht (m) |
8.8 |
10.5 |
11.6 |
12.4 |
12.5 |
| #7 Nozzle - Lime (2.78 mm) | |||||
| Flow (L/hr) |
241 |
295 |
341 |
382 |
418 |
| SA Diameter at 0.46 m ht (m) |
11.1 |
12.7 |
13.3 |
13.7 |
13.9 |
| LA Diameter at 0.46 m ht (m) |
9.6 |
11.3 |
12.2 |
12.7 |
12.8 |
| #8 Nozzle - Lavender (3.18 mm) | |||||
| Flow (L/hr) |
318 |
388 |
450 |
502 |
550 |
| SA Diameter at 0.46 m ht (m) |
11.7 |
13.3 |
13.7 |
14.2 |
14.3 |
| LA Diameter at 0.46 m ht (m) |
10.4 |
11.9 |
12.7 |
13 |
13.1 |
| #9 Nozzle - Grey (3.57 mm) | |||||
| Flow (L/hr) |
409 |
500 |
577 |
645 |
706 |
| SA Diameter at 0.46 m ht (m) |
12.4 |
13.9 |
14.2 |
14.5 |
14.6 |
| LA Diameter at 0.46 m ht (m) |
10.8 |
12.4 |
13 |
13.3 |
13.4 |
| #10 Nozzle - Turquoise (3.97 mm) | |||||
| Flow (L/hr) |
504 |
618 |
713 |
797 |
874 |
| SA Diameter at 0.46 m ht (m) |
12.8 |
14.3 |
14.6 |
14.8 |
14.9 |
| LA Diameter at 0.46 m ht (m) |
11 |
12.5 |
13.1 |
13.4 |
13.6 |
| #11 Nozzle - Yellow (4.37 mm) | |||||
| Flow (L/hr) |
611 |
749 |
865 |
968 |
1061 |
| SA Diameter at 0.46 m ht (m) |
13.1 |
14.6 |
14.9 |
15.1 |
15.3 |
| LA Diameter at 0.46 m ht (m) |
11.1 |
12.8 |
13.3 |
13.6 |
13.7 |
| #12 Nozzle - Red (4.76 mm) | |||||
| Flow (L/hr) |
734 |
899 |
1038 |
1161 |
1272 |
| SA Diameter at 0.46 m ht (m) |
13.4 |
14.9 |
15.3 |
15.4 |
15.6 |
| LA Diameter at 0.46 m ht (m) |
11.3 |
13 |
13.4 |
13.7 |
13.9 |
| #13 Nozzle - White (5.16 mm) | |||||
| Flow (L/hr) |
863 |
1056 |
1222 |
1365 |
1497 |
| SA Diameter at 0.46 m ht (m) |
13.6 |
15.1 |
15.4 |
15.5 |
15.7 |
| LA Diameter at 0.46 m ht (m) |
11.4 |
13.1 |
13.6 |
13.9 |
14 |
| #14 Nozzle - Blue (5.56 mm) | |||||
| Flow (L/hr) |
999 |
1224 |
1415 |
1583 |
1735 |
| SA Diameter at 0.46 m ht (m) |
13.7 |
15.3 |
15.6 |
15.7 |
15.9 |
| LA Diameter at 0.46 m ht (m) |
11.6 |
13.3 |
13.7 |
14 |
14.2 |
