Features
- Only one moving part for longer life
- Low evaporative loss at low pressures
- Inlet size: 15mm NPT male
- Flow rates: 170 to 495 L/hr
Overview
The Mini-Wobbler uses Senninger’s off-center rotary-action wobbler technology. It provides extremely uniform coverage over a large diameter at low operating pressures and produces a gentle application of solutions.
Nozzle Specifications
| Nozzles |
BAR |
|
|
1.38 |
1.72 |
|
| #5 Nozzle - Beige (1.98 mm) | ||
| Flow (L/hr) |
170 |
191 |
| Diameter at 0.91 m ht (m) |
9.2 |
9.5 |
| Diameter at at 1.83 m ht (m) |
9.8 |
9.9 |
| #6 Nozzle - Gold (2.38 mm) | ||
| Flow (L/hr) |
250 |
284 |
| Diameter at 0.91 m ht (m) |
9.5 |
9.6 |
| Diameter at at 1.83 m ht (m) |
10.4 |
10.5 |
| #8 Nozzle - Lavender (3.18 mm) | ||
| Flow (L/hr) |
443 |
495 |
| Diameter at 0.91 m ht (m) |
9.6 |
9.8 |
| Diameter at at 1.83 m ht (m) |
10.8 |
11 |
