Nelson 150 Series Big Gun Sprinkler
$4,788.62
The 150 Series sprinklers have larger nozzle sizes that allow for wider sprinkler spacing in industrial and solid set applications, and wider row spacing in traveler applications.
The Big Gun® offers solutions for diverse applications across a wide range of pressures and flow rates. Multiple trajectories, connection styles, and custom options allow you to configure the perfect solution for any application.
Overview
The 150 Series sprinklers have larger nozzle sizes that allow for wider sprinkler spacing in industrial and solid set applications, and wider row spacing in traveler applications.
The 150 Series is available with the widest range of options and accessories in the industry. Full or Part Circle models, multiple trajectories (including an adjustable model), three different nozzle styles, special coatings and effluent options – we have a unique solution for any application.
Connections: Flanged / Threaded Adapters
Nozzles: Taper Bore / Taper Ring / Ring
Options: Anodized / Anodized & Powder Coated / Stainless Steel / Effluent Bearing Assembly / Vaneless Range Tube
Accessories: Counterbalance Kit / 12° Wedge Kit / Arc Timer
Flow: 90-630 gpm (20-143 m3/hr)
Pressure: 50-120 psi (3.5-8.25 bar)
Radius: 120-240 ft (36-73 m)
Trajectory: 21°, 24°, 27°, 43°, 15-45°
- BIG-GUN-BROCHURE_MARCH-2020.pdf Download →
- Big Gun Brouchure Download →
- Performance-from-BIG-GUN-BROCHURE_MARCH-2020.pdf Download →
- Big Gun Performance Download →
- Big-Gun_SR150_Operations-and-maintanance.pdf Download →
- SR150 Operations & Maintenance Download →
- Big-Gun-Trouble-shooting.pdf Download →
- Big Gun Troubleshooting Download →
- Big-Gun_SR100SR150-Drivearm-CounterWeight-Maint-Kit.pdf Download →
- SR100 & SR150 Drive Arm and Counterweight Instructions Download →
