Rain Bird Maxi-Paw Pop Up Impact Sprinkler

Features:

• Proven impact drive.
• Straight-through flow for superior performance in dirty water.
• Heavy-duty plastic case with sturdy, reinforced ribbed design.
• Double-weighted arm for slower rotation and increased distance of throw.
• Adjustable arm spring for low-pressure and low-flow operation.
• 360° Full-circle OR arc adjustable from 20° to 340°.
• Inlet filter screen and pressure-activated wiper seal protect the internal assembly from debris to ensure positive pop-up and retraction.
• 15 mm side inlet & 20 mm bottom inlet.
• Side or combination bottom inlet for design flexibility. Side inlet installation is not recommended in freezing climates.
• Optional internal Seal-A-Matic (SAM) prevents puddling and erosion caused by low head drainage and saves water.
• Serviceable through the top of the case. The Rainbird Installation Wrench is useful for this.
• Three-year trade warranty.

Specifications:

• Precipitation Rate: 7 to 30 mm/h
• Radius: 6.7 to 13.7 m
• Radius with Radius Reduction Screw: 5.4 m
• Pressure: 1.7 to 4.1 Bar
• Flow: 0.34 to 1.91 m3/h
• 15 mm side inlet & 20 mm bottom inlet

Overview

These heavy-duty impacts have the strength and performance of industrial and commercial products yet are easy to install and operate.

The Maxi-Paw’s powerful throw permits maximum spacing and offers superior close-in watering and uniform water distribution. Low-pressure loss and an efficient, straight-through flow design conserve energy and are ideal for dirty water applications.

The optional Seal-A-Matic™ prevents run-off, puddling, and erosion caused by low head drainage.

Brand: Rainbird

Connection: 15mm side inlet & 20mm bottom inlet

Dimensions

• Overall height: 23.6 cm
• Pop-up height: 7.6 cm
• Exposed surface diameter: 12.7 cm
