The ESP-TM2 irrigation controller is the perfect option for essential residential solutions. Building upon Rain Bird’s legacy of The Intelligent Use of Water®, this controller offers simple water-saving features that you will use. With the flexibility of 3 programs and four start times available per program, you can tailor your watering schedule to your landscape’s needs. The ESP-TM2 provides the Extra Simple Programming interface you are familiar with in a controller built to last! Make your controller SMART by adding the LNK WiFi module and a Rain Bird Rain Sensor. Best of all, you can upgrade the ESP-TM2 into a WiFi-enabled controller by simply installing a new LNK WiFi Module without having to replace the entire unit. Make your controller SMART with EPA WaterSense certification by adding the LNK WiFi module and a WR2 rain sensor.
Features
Quick to Install
- Available in 4, 6, 8, and 12 station models
- Suitable for indoor or outdoor installations
- Factory-installed outdoor-rated power cord for your convenience (Australian 230v models only)
Simple to Program
- Quickly program a schedule in just three steps
- Three available programs (A, B, C) with up to 4 start times for each program
- Simple one-touch manual watering
- NEW large back-lit LCD for improved visibility in low-light and direct sunlight conditions
WiFi Connectivity
- By simply plugging in a Rain Bird LNK WiFi Module (sold separately), users can access, operate and monitor their irrigation system from anywhere.
- Internet-based weather info makes daily adjustments to the irrigation schedule. Save up to 30% water.
- For support and help with the LNK WiFi and Rain Bird Mobile App, please visit http://wifi-pro.rainbird.com/support/.
Advanced Features
- Contractor Default™ allows you to save and restore your custom schedule quickly.
- Delay Watering up to 14 days and automatically resume watering after the set delay has elapsed
- Bypass Rain Sensor for any station gives you the ability to customise which stations react to a rain sensor.
- Set Permanent Days Off per program to ensure watering never occurs on days when maintenance crews are on-site (for Odd/Even/ Cyclic schedules)
- Seasonal Adjust by the program allows you to reduce or increase watering by the program quickly.
Specs
Controller Hardware
- Plastic wall-mount cabinet with door
- Mounting screws with anchor shields
- Factory-installed pigtail (Available on 120v and Australian 230v models only)
Controller Features
- Familiar, easy to navigate user interface
- Rain sensor input with bypass capability
- Master valve/pump start circuit.
- Nonvolatile (100 years) storage memory
- Electronic diagnostic circuit breaker
- Remote accessory port for Rain Bird approved accessory devices.
Scheduling Features
- Program based scheduling with three individual programs and four independent start times per program for 12 total start times
- Watering schedule options: Custom Days of the week, ODD or EVEN calendar days, or Cyclic (every 1 – 30 days)
Advanced Features
- Compatible with Rain Bird LNK WiFi Module (sold separately) to enable remote programming, operation and alerts from the Rain Bird mobile app.
- Manual Watering option for all stations, a single station or an individual program
- Seasonal Adjust applied to all programs or an individual program
- Delay Watering up to 14 days (applies only to stations set to obey Rain sensor)
- Permanent Days Off (for Odd, Even or Cyclic programming)
- Sensor bypass for all programs or individual stations
- Adjustable delay between stations
- Contractor Default™ Program Save and Restore the saved program(s)
- Master Valve on/off by the station
- Automatic short detection with station-specific alarm messages
Operating Specifications
- Station timing: 1 minute to 6 hours
- Seasonal Adjust: 5% to 200%
Max operating temperature
- 230v models 122°F (50°C)
Electrical Specifications
- Input required: 230VAC (±10%) @ 50/60Hz
- Output: .65A at 24VAC on 230v models
- Master Valve/Pump Start Relay
- External battery backup not required. Nonvolatile memory permanently saves the current programming, and a ten-year life lithium battery maintains the controllers time and date during power outages.
Dimensions
- Width: 7.92 in. (20,1 cm)
- Height: 7.86 in. (20,0 cm)
- Depth: 3.51 in. (9,0 cm)
