Rain Bird 5000/5000+ Rotor Pop Up Sprinklers 100mm

$29.19$59.79

Unmatched Performance for Residential, Light Commercial and Commercial Applications. Engineered to deliver a uniform spray pattern, giving you superior distribution uniformity and consistently greener turf with less water.

Details Code Price Quantity
Full Circle – Plastic 5004FC $29.19
 incl GST
Part Circle – Plastic 5004PC $29.19
 incl GST
5004+ Part Circle + SAM – Stainless Steel Riser 5004+PCSRSS $59.79
 incl GST
5004+ Full Circle + SAM – Stainless Steel Riser 5004+FCSRSS $59.79
 incl GST
Lilac Part Circle + SAM | for Non Potable Systems – Stainless Steel Riser 5004+PCSRSSNP $59.50
 incl GST
View Full Product Page

Features:

  • Seal-A-Matic (SAM) check valve holds up to 7 feet (2.1m) of elevation change to prevent puddling and erosion caused by low head drainage.
  • Stainless steel risers to help deter vandalism on public turf areas

Operating Range:

  • Precipitation rate: 5 to 26 mm/h
  • Radius: 7.6 to 15.2 m
  • Radius may be reduced up to 25% with radius reduction screw
  • Pressure: 1.7 to 4.5 bar
  • Flow Rate: 4.2 to 36.6 l/m

Specifications:

  • 20mm female bottom threaded inlet
  • Reversing / Part circle adjustment 40° – 360°
  • Full circle only adjustment 360°

Pressure Regulating

  • In-stem pressure regulator (PRS) reduces operating pressure to 3.1 bar for optimal nozzle performance.
  • Save Water
  • Eliminates head-to-head pressure variations
  • Eliminates misting due to high pressure
  • Improves nozzle distribution uniformity by operating the nozzle at optimum pressure

Brand: Rainbird.

Series: 5004+

Inlet Connection: 20mm (3/4") Female

100mm (4") Pop up Sprinklers with Stainless Steel Risers.

100mm (4") Pop up Sprinklers with Plastic Risers.

Unmatched Performance for Residential, Light Commercial and Commercial Applications

Engineered to deliver a uniform spray pattern, giving you superior distribution uniformity and consistently greener turf with less water.

Rain Curtain Technology:

  • Rain Curtain Nozzles standard on all 5000 Series Rotors
    • Large water droplets for greater wind resistance
    • Effective close-in watering
    • Even distribution over the entire radius
  • Tree of nozzles including four low angles (angle of trajectory 10°) and eight standard angle Rain Curtain Nozzles (angle of trajectory 25°) provides 7.6m to 15.2m distance of throw.
  • Self-aligning nozzles
Pop-Up-Sprinkler-Range-Chart-3
