Rain Bird 1800 Series Pop-Up Sprinkler Bodies

$5.50$40.50



  • Co-molded wiper seal provides unmatched resistance to grit, pressure and the environment
  • Constructed of time-proven UV-resistant plastic and corrosion-resistant stainless steel parts, ensuring long product life
  • Precision controlled flush at pop-down clears debris from unit, assuring positive stem retraction in all soil types



Details Code Price Quantity
50mm Pop-Up - Body Only 1802 $5.50
 ex GST
100mm Pop-Up - Body Only 1804 $6.24
 ex GST
100mm Pop-Up - SAM Check Valve - Body Only 1804SAM $9.80
 ex GST
100mm Pop-Up - 2.1 Bar in-stem Pressure Regulation - SAM Check Valve - Body Only 1804SAMP30 $17.00
 ex GST
100mm Pop-Up - 3.1 Bar in-stem Pressure Regulation - SAM Check Valve - Body Only 1804SAMP45 $17.00
 ex GST
150mm Pop-Up - Body Only 1806 $19.50
 ex GST
150mm Pop-Up - SAM Check Valve - Body Only 1806SAM $22.50
 ex GST
300mm Pop-Up - Body Only 1812 $37.50
 ex GST
300mm Pop-Up - SAM Check Valve - Body Only 1812SAM $40.50
 ex GST
150mm Pop-Up - 3.1 Bar in-stem Pressure Regulation - SAM Check Valve - Body Only 1806SAMP45 $28.50
 ex GST
View Full Product Page

Features

  • Co-molded wiper seal provides unmatched resistance to grit, pressure and the environment
  • Constructed of time-proven UV-resistant plastic and corrosion-resistant stainless steel parts, ensuring long product life
  • Precision controlled flush at pop-down clears debris from unit, assuring positive stem retraction in all soil types
  • Two-piece ratchet mechanism allows easy nozzle pattern alignment and provides added durability
  • Five-Year Trade Warranty

The 1800 Series accepts all Rain Bird spray nozzles.

  • Flow-by: 0 gpm at 8 psi (0.6 bar) or greater;  0.10 gpm (0.02 m³/h; 0.36 l/m) otherwise

Operating Range

  • Spacing:  2.5 to 24 feet (0.8 to 7.3m)*
  • Pressure:  15 to 70 psi (1.0 to 4.8 bar)

Dimensions

  • ½" (15/21) NPT female threaded inlet
  • Models  and height:
    • 1802: 4" (10.2 cm) body height; 2" pop-up height (5.1 cm)
    • 1804: 6" (15.2 cm) body height; 4' pop-up height (10.2 cm)
    • 1806: 9 3⁄8" (23.8 cm) body height; 6" pop-up height (15.2 cm)
    • 1812: 16" (40.6 cm) body height; 12" pop-up height (30.5 cm)
  • Exposed  surface diameter: 2¼ " (5.7 cm)

1800 Series Pop-Up Sprinkler Bodies DO NOT include spray nozzles

Overview

Fixed Arc MPR Nozzles and Variable Arc Nozzles are available to suit 1800 series sprinkler bodies

Size is for the height of the Pop-Up and does not include the height of the sprinkler body.

Installed in parks and backyards across the globe, Rain Bird's 1800 Series is the #1 commercial-grade irrigation spray head brand in the world.

Chosen for its reliability, heavy-duty materials and versatility, the 1800 Series has first-rate quality built in for reliable operation and long life. Their superior components and features make them the spray heads of choice for a wide variety of applications.

Brand: Rain Bird.

Connection: 15mm BSPF

Pressure: 1.0 to 4.8 bar.
