Nelson R10 Rotator Sprinkler – Flow Control Nozzles

$9.70

Filling the need for small, low-volume sprinklers that perform reliably in the mid-range between a micro- and regular-size sprinkler, the R10 Rotator® is right on target.

Details Code Price Quantity
Red Plate | 0.35 Flow Control Nozzle NR10FC-ACME-2935 $9.70
White Plate | 0.50 Flow Control Nozzle NR10FC-ACME-4950 $9.70
Orange Plate | 0.50 Flow Control Nozzle NR10FC-ACME-41550 $9.70
View Full Product Page

Overview

Filling the need for small, low-volume sprinklers that perform reliably in the mid-range between a micro- and regular-size sprinkler, the R10 Rotator® is right on target.

R10 Rotator - FC Nozzles

Choose from the red, white or orange plates with either the 0.35FC or 0.50FC Nozzle. Applications include: under-tree irrigation and environmental control of tree fruit, vine, and tree nut crops — as well as overhead irrigation, cooling, and environmental control in tree, vine, small fruit, and nursery crops.

System Types:

  • Permanent set using either PVC pipe or polyethylene pipe laterals
  • Portable pipe systems including aluminum, polyethylene and PVC.



Incorporating the same proven, patented drive principle and advanced sprinkler technology used in other Nelson Rotators, the R10's are making their mark in a wide variety of orchard and field irrigation applications.




Plate Series: Plate Options: Nozzle Options: Nozzle Performance (Nominal Flow): Recommended Pressure Range (BAR):
P2 9° Red 0.35 FC 79.5LpH 1.75 - 3.25
P4 9° White,
15° Orange
0.50 FC 114 LpH 1.75 - 3.25

Within the recommended pressure range the flow control nozzles will flow regulate within a flow range of no more than 0% greater and 10% less than the nominal flow.
