Hunter Wireless Valve Link

Name: Hunter Wireless Valve Link
SKU: WVLXXX
Availability: InStock

Enable convenient wireless valve control for ICC2 and HCC Controllers with the highly flexible and easy-to-install Wireless Valve Link.

Number of Stations 54 plus master valve

Type Controller accessory, wireless valve control

Works with Hunter ICC2 and HCC Controllers
Adds up to 54 valves (+ P/MV) over 650 m line-of-sight, or more with a Repeater
Licence-free LoRa® Technology enables wireless communication directly to the valve box — no copper field wiring required
Combines with conventional ICM or EZDS Modules for ultimate flexibility
Is compatible with Centralus™ and Hydrawise™ Irrigation Management Platforms

Details	Code	Price	Quantity
Single-station Wireless Valve Link (antenna included)	WVL100	$419.18 incl GST	Hunter Wireless Valve Link quantity
2-station Wireless Valve Link (antenna included)	WVL200	$489.04 incl GST	Hunter Wireless Valve Link quantity
4-station Wireless Valve Link (antenna included)	WVL400	$558.90 incl GST	Hunter Wireless Valve Link quantity
Wireless Valve Output Module for ICC2/HCC Controllers	WVOM	$489.04 incl GST	Hunter Wireless Valve Link quantity
Battery-operated Wireless Solar Repeater for WVL range extension (1 per system, max)	RPT	$856.98 incl GST	Hunter Wireless Valve Link quantity

Details

Code

Price

Quantity

Single-station Wireless Valve Link (antenna included)

WVL100

$419.18
incl GST

2-station Wireless Valve Link (antenna included)

WVL200

$489.04
incl GST

4-station Wireless Valve Link (antenna included)

WVL400

$558.90
incl GST

Wireless Valve Output Module for ICC2/HCC Controllers

WVOM

$489.04
incl GST

Battery-operated Wireless Solar Repeater for WVL range extension (1 per system, max)

RPT

$856.98
incl GST

OPERATING SPECIFICATIONS

Low-profile, waterproof valve box lid mount for field durability
- Requires a 38 mm diameter hole in the valve box lid for installation (hole saw included with WVOM-E output module)
Two-way communications confirm field performance
433 MHz LoRa radio
1-, 2-, and 4-station configurations to optimise field installations
Uses Hunter DC-Latching Solenoids
WVL maximum distance to solenoid: 30 m, depending on wire size
One or two 9 VDC batteries per WVL
Solar recharging option with SP-WVL
Built-in site survey and manual test functions ensure successful operation once installed in the field
Easy setup with free iOS® and Android™ Bluetooth® app
Approvals:
- FCC, UL, CE, ISED Canada, RCM, and TDRA approved
- WVL transceivers are IP68 rated
- The repeater is IP55 rated
Warranty period: 2 years
