Hunter Wireless Valve Link
Price range: $419.18 through $856.98

Enable convenient wireless valve control for ICC2 and HCC Controllers with the highly flexible and easy-to-install Wireless Valve Link.

Number of Stations 54 plus master valve

Type Controller accessory, wireless valve control

Works with Hunter ICC2 and HCC Controllers

Adds up to 54 valves (+ P/MV) over 650 m line-of-sight, or more with a Repeater

Licence-free LoRa® Technology enables wireless communication directly to the valve box — no copper field wiring required

Combines with conventional ICM or EZDS Modules for ultimate flexibility

Is compatible with Centralus™ and Hydrawise™ Irrigation Management Platforms

Details Code Price Quantity

Single-station Wireless Valve Link (antenna included) WVL100 $419.18 incl GST

2-station Wireless Valve Link (antenna included) WVL200 $589.17 incl GST

4-station Wireless Valve Link (antenna included) WVL400 $672.85 incl GST

Wireless Valve Output Module for ICC2/HCC Controllers WVOM $489.04 incl GST

Battery-operated Wireless Solar Repeater for WVL range extension (1 per system, max) RPT $856.98 incl GST

SKU: WVLXXX

OPERATING SPECIFICATIONS

Low-profile, waterproof valve box lid mount for field durability

Requires 38 mm diameter hole in valve box lid for installation (hole saw included with WVOM-E output module)

Two-way communications confirm field performance

433 MHz LoRa radio

1-, 2-, and 4-station configurations to optimise field installations

Uses Hunter DC-Latching Solenoids

WVL maximum distance to solenoid: 30 m, depending on wire size

One or two 9 VDC batteries per WVL

Solar recharging option with SP-WVL

Built-in site survey and manual test functions ensure successful operation once installed in the field

Easy setup with free iOS® and Android™ Bluetooth® app

Approvals:

FCC, UL, CE, ISED Canada, and RCM, and TDRA approved

WVL transceivers are IP68 rated

Repeater is IP55 rated

Warranty period: 2 years
