Structure and Features
- Brand: NaanDanJain
- Series: ClickTif HD
- Four dripper design elements minimize clogging:
- Protected water inlet
- Flushing mechanism of regulating diaphragm
- Strong turbulent flow in labyrinth enables continual cleaning and flushing
- Large water passages
- Color-coded for identification of discharge and mode
- Standard 5 mm tapered outlet for working with connectors or barb outlet for 3/5 tube
- Chemical-resistant, high-grade plastic for precision and durability
Specifications
- Regulating pressure range: 0.5 - 4.0 bar
- Very low CV
- Minimum recommended working pressure 1.0 Bar
- Filtration Recommendation: 130 micron
Overview
ClickTif PC Button Drippers with Barbed Outlet: Heavy Duty, Pressure Compensating (PC) Â on-line Button Drippers
Barbed Outlet suits 3/5 tube.
3/5 Tube has a 3mm Internal Diameter with 5mm External Diameter
Which Dripper works for you?
